Using ImageMagick and Tesseract to sort TIFFs on Windows

Recently I wrote a post about my search for a TIFF iFilter that would enable me to use VBScript to query a Windows Indexing Services server for file management.

I found that since OCR is never always 100% accurate, neither were my attempts at sorting all the inbound EMR faxes we get each day.

I did however, find Tesseract, a great product that was originally developed by HP and proprietary, and is now developed by Google and licensed under the Apache License v2, open source.

It is one of the most accurate open source OCR engines available. It is quite basic, and in the version you obtain from the project page, it only operates from the command line, and without the libtiff library, will only do it's work on un-compressed TIFFs. More information can be found on the project pages, and Wikipedia. Doing some scouring, I aso found a front-end, and ArchivistaBox, a complete document management system.

ImageMagickImage via Wikipedia

I'm using it in Windows, so I needed to do one of two things: recompile the sources in Visual Studio Express to include the libtiff libraries, or use the convert program that is bundled with ImageMagick. I tried to recompile but ran into too many issues, so fell back to ImageMagick.

Following is the script I kick off daily to sort these:

Option Explicit

Dim oShell
Dim sCwhhm
Dim sAqscan
Dim sConv
Dim sOpts
Dim sTess
Dim FSO
Dim sFolder
Dim sFile
Dim sFileColl
Dim inFile
Dim sClinic
Dim sDOS
Dim sMoveTo
Dim sNumBse, sNumMdn, sNumUnk
Dim sStartTime, sFinishTime, sMail, sLog
Dim i, x, l, arrFileLines()

Set oShell = CreateObject("WScript.Shell")
Set FSO = CreateObject("Scripting.FileSystemObject")
Set sLog = FSO.CreateTextFile("C:\scripts\Log\CWHHM_FAXMOVELOG.TXT", True)

sStartTime = Now()

sLog.WriteLine(sStartTime & "---------------------------")

' ///////////////////////////////////////////
' Set the source and destination
' ///////////////////////////////////////////
sCwhhm = "F:\Incomi~1\CWHHM\"
sAqscan = "F:\Scanne~1\Aquarius\14CWHHM\"

' ///////////////////////////////////////////
' Set the convert program and flags
sConv = "C:\Progra~1\ImageM~1.3-Q\convert.exe"
sOpts = "-density 150x150 -compress none"

' ///////////////////////////////////////////
' Set the tesseract program
sTess = "C:\Progra~1\tesser~1.00\tesser~1.exe"

' ///////////////////////////////////////////
' First clean up the directory so we can
' build a list of all tifs
' ///////////////////////////////////////////

If (FSO.FileExists(sCwhhm & "Thumbs.db")) Then
    FSO.DeleteFile(sCwhhm & "Thumbs.db")
End If

If (FSO.FileExists(sCwhhm & "tesseract.log")) Then
    FSO.DeleteFile(sCwhhm & "tesseract.log")
End If

' ///////////////////////////////////////////
' Set the folder and file collection
' ///////////////////////////////////////////
Set sFolder = FSO.GetFolder(sCwhhm)
Set sFileColl = sFolder.Files

' ///////////////////////////////////////////
' Loop over remaining files
' ///////////////////////////////////////////
For Each sFile in sFileColl

    ' ///////////////////////////////////////////
    ' Convert the file to an uncompressed format
    oShell.Run sConv & " " & sCwhhm & sFile.Name & " " & sOpts & " " & sCwhhm & "out.tif", 0, true

    ' ///////////////////////////////////////////
    ' Now OCR it, then delete the old tif
    oShell.Run sTess & " " & sCwhhm & "out.tif " & sCwhhm & "ocr", 0, true
    FSO.DeleteFile(sCwhhm & "out.tif")


    ' ///////////////////////////////////////////
    ' Read the file in to our array

    Set inFile = FSO.OpenTextFile(sCwhhm & "ocr.txt", 1)

    i = 0
    Redim arrFileLines(i)

    Do Until inFile.AtEndOfStream
        Redim Preserve arrFileLines(i)
        arrFileLines(i) = inFile.ReadLine
        i = i + 1
    Loop

    ' close and delete the file, we don't need it anymore
    inFile.Close
    FSO.DeleteFile(sCwhhm & "ocr.txt")

    ' ///////////////////////////////////////////
    ' Now read the contents of the file, from the top down,

    For l = 0 to UBound(arrFileLines)

        ' ///////////////////////////////////////////
        ' Check for the header
        If UCase(Left(arrFileLines(l), 6)) = "CENTER" Then

            ' ///////////////////////////////////////////
            ' Test for the progress line on the next line, 3
            If UCase(Left(arrFileLines(l + 1), 8)) = "PROGRESS" Then


                ' ///////////////////////////////////////////
                ' We are pretty sure the next line, 4, is a clinic name
                sClinic = UCase(arrFileLines(l + 2))

                Select Case sClinic
                    Case "MERIDIAN CLINIC"
                        sClinic = "MDN\"
                        sNumMdn = sNumMdn + 1
                    Case "BOISE CLINIC"
                        sClinic = "BSE\"
                        sNumBse = sNumBse + 1
                    Case Else
                        sClinic = "UNK\"
                        sNumUnk = sNumUnk + 1
                 End Select

                ' ///////////////////////////////////////////
                ' Get the DOS, which is supposed to be on line
                ' 8 of a progress report, but we'll check a couple
                ' to be sure. We are on line 2, CENTER.

                For x = 4 to 8
                    sDOS = UCase(Left(arrFileLines(l + x), 4))

                    If sDOS = "DATE" Then

                        sDOS = Trim(Replace(Mid(arrFileLines(l + x), 17, 11), "/", ""))

                            sMoveTo = sAqscan & sClinic & sDOS & "\"

                            If FSO.FolderExists(sMoveTo) Then
                               FSO.MoveFile sCwhhm & sFile.Name, sMoveTo
                            Else
                               On Error Resume Next
                               FSO.CreateFolder(sMoveTo)
                               If Err.Number <> 0 Then
                                sLog.WriteLine("ERROR: " & Err.Number & " - " & Err.Description)
                                sLog.WriteLine("ERROR: " & sFile.Name & " was going to be moved to " & sMoveTo)
                                Set sMail = FSO.CreateTextFile("C:\Temp\TEMPMAIL.TXT", True)
                                sMail.WriteLine("TO: " & Chr(34) & "JOHN CROSON" & Chr(34) & "")
                                sMail.WriteLine("FROM: " & Chr(34) & "IHBS Administrator" & Chr(34) & "")
                                sMail.WriteLine("SUBJECT: CWHHM EMR File Sorting")
                                sMail.WriteBlankLines(1)
                                sMail.WriteLine("There has been an error. Check c:\scripts\log\CWHHM_FAXMOVELOG.TXT")
                                sMail.Close
                                FSO.MoveFile "C:\Temp\TEMPMAIL.TXT", "\\ibsts\c$\Inetpub\mailroot\Pickup\"
                               End If
                               FSO.MoveFile sCwhhm & sFile.Name, sMoveTo
                            End If
                            Exit For
                    End If
                Next


            Else
                ' //////////////////////////////////////////
                ' This must be another file type, step to the next line
                sClinic = UCase(Left(arrFileLines(l + 1), 5))

                Select Case sClinic
                   Case "MERID"
                        sClinic = "MDN\"
                        sNumMdn = sNumMdn + 1
                   Case "BOISE"
                        sClinic = "BSE\"
                        sNumBse = sNumBse + 1
                   Case Else
                        sClinic = "UNK\"
                        sNumUnk = sNumUnk + 1
                End Select

                ' ///////////////////////////////////////////
                ' Get the DOS, which could be on line
                ' 7 through 12.

                For x = 5 To 15
                    sDOS = UCase(Left(arrFileLines(l + x), 4))

                    If sDOS = "DATE" Then

                        sDOS = Trim(Replace(Mid(arrFileLines(l + x), 17, 11), "/", ""))
                            sMoveTo = sAqscan & sClinic & sDOS & "\"

                            If FSO.FolderExists(sMoveTo) Then
                               FSO.MoveFile sCwhhm & sFile.Name, sMoveTo
                            Else
                               On Error Resume Next
                               FSO.CreateFolder(sMoveTo)
                               If Err.Number <> 0 Then
                                sLog.WriteLine("ERROR: " & Err.Number & " - " & Err.Description)
                                sLog.WriteLine("ERROR: " & sFile.Name & " was going to be moved to " & sMoveTo)
                                Set sMail = FSO.CreateTextFile("C:\Temp\TEMPMAIL.TXT", True)
                                sMail.WriteLine("TO: " & Chr(34) & "JOHN CROSON" & Chr(34) & "")
                                sMail.WriteLine("FROM: " & Chr(34) & "IHBS Administrator" & Chr(34) & "")
                                sMail.WriteLine("SUBJECT: CWHHM EMR File Sorting")
                                sMail.WriteBlankLines(1)
                                sMail.WriteLine("There has been an error. Check c:\scripts\log\CWHHM_FAXMOVELOG.TXT")
                                sMail.Close
                                FSO.MoveFile "C:\Temp\TEMPMAIL.TXT", "\\ibsts\c$\Inetpub\mailroot\Pickup\"
                               End If
                               FSO.MoveFile sCwhhm & sFile.Name, sMoveTo
                            End If
                            Exit For
                    End If
                Next

             sClinic = ""
             sDOS = ""

            End If  '<- Progress Test
       Exit For
       End If   '<- Header Test

    Next
Next

sFinishTime = Now()

sLog.WriteLine(sFinishTime & "---------------------------")
sLog.Close

' //////////////////////////////
' Now send an email notification that the
' files are ready.
Set sMail = FSO.CreateTextFile("C:\Temp\TEMPMAIL.TXT", True)
sMail.WriteLine("TO: " & Chr(34) & "JOHN CROSON" & Chr(34) & "")
sMail.WriteLine("FROM: " & Chr(34) & "IHBS Administrator" & Chr(34) & "")
sMail.WriteLine("SUBJECT: CWHHM EMR File Sorting")
sMail.WriteBlankLines(1)
sMail.WriteLine("CWHHM Electronic Medical Record sorting is finished.")
sMail.WriteBlankLines(1)
sMail.WriteLine("Start time was " & sStartTime & ". Finish time was " & sFinishTime & ".")
sMail.WriteBlankLines(1)
sMail.WriteLine("The number of Boise files was " & sNumBse & ".")
sMail.WriteBlankLines(1)
sMail.WriteLine("The number of Meridian files was " & sNumMdn & ".")
sMail.WriteBlankLines(1)
    If sNumUnk > 0 Then
        sMail.WriteLine("The number of Unkown files was " & sNumUnk & ".")
    End If

sMail.Close
FSO.MoveFile "C:\Temp\TEMPMAIL.TXT", "\\ibsts\c$\Inetpub\mailroot\Pickup\"
